380 Series Port Sizes: 3/8, 1/2, 3/4
Product Catalog
Operating Instructions
Operating Instructions
Operating Instructions
- Individual general purpose filter, coalescing filter, and adsorbing filter
- General purpose filter removes gross contaminants
- Coalescing filter removes oil mists, aerosols, and minute particles
- Adsorbing filter effectively eliminates odors from Freons, alcohols, esters, ketones, and up to 99% of most hydrocarbons
- Modular or in-line mounting
- 5-μm-rated polyethylene general purpose filter element; optional bronze
- 0.3-μm-rated coalescing filter element; optional 0.01-μm element
- Polycarbonate plastic bowls with steel shatter guards; optional metal bowls
- Optional extended bowls include higher capacity filter elements for coalescing and adsorbing filters
- Automatic internal drain for general purpose and coalescing filters. Manual drain for adsorbing filter
- Differential pressure gauge on coalescing filter to indicate when filter element needs changing
+
380 Series
Contact Master Pneumatic for Information
+
