10 Series FC10-2
- Modular assembly and mounting
- Threaded ports or quick-connect fittings for tubing up to 10 mm in diameter
- 0.3-μm-rated coalescing filter element; optional 0.01-μm-rated element
- High-strength polycarbonate plastic filter bowl; optional aluminum bowl
- Automatic internal drain; optional manual drain
FC10-2
$63.37
Quantity
Estimated Ship Date: 07/16/2026
*Estimated Ship Date based on standard manufacturing times for quantities of 10 or less. Shipments will be made anywhere in the United States.
Product Information
| Mounting | Modular/Inline |
| Bowl Type | Plastic |
| Bowl Capacity | 2 oz (60 ml) |
| Connection | Threaded Ports |
| Port Size | 1/4" |
| Port Thread | NPTF |
| Condensate Drain | Manual - Drain Knob |
| Filtration Rating | 0.3 µm |
| Element Material | Borosilicate Glass Fiber |
| Operating Pressure | 0 to 150 psig (0 to 10 bar) |
| Ambient/Medium Temperature | -4 to 125°F (-20 to 52°C) |
| Medium Temperature Caution | For temperatures below 35°F (2°C) air must be free of water vapor; Compressed air to ISO 8573-1:2010 [-:3:-]. |
| Fluid Medium | Compressed Air |
| Body Material | Acetal |
| Bowl Material | Polycarbonate |
| Seal Material | Nitrile (Buna-N) |
| Weight | 0.49 lb (0.22 kg) |
+
10 Series
FC10-2
Contact Us for a 3D Model
+
10 Series
FC10-2
Contact Master Pneumatic for Ordering Information
+
