100 Series BF101L-3E5
- Modular assembly and mounting
- Threaded ports or quick-connect fittings for tubing up to 10 mm in diameter
- 5-μm-rated polyethylene filter element; optional sintered bronze elements
- High-strength polycarbonate plastic filter bowl; optional metal bowl
- Automatic internal drain; optional manual drain
Product Information
| Mounting | Modular/Inline |
| Bowl Type | Metal |
| Bowl Capacity | 8 oz (240 ml) |
| Connection | Threaded Ports |
| Port Size | 3/8" |
| Port Thread | NPTF |
| Drain Type | Internal |
| Condensate Drain | Manual – Drain Knob |
| Element Material | Sintered Bronze |
| Filtration Rating | 5 µm |
| Operating Pressure | 0 to 200 psig (0 to 14 bar) |
| Differential Pressure Gauge | Large Dual Face Gauge |
| Ambient/Medium Temperature | -4° to 175°F (-20° to 80°C) |
| Medium Temperature Caution | For temperatures below 35°F (2°C) air must be free of water vapor; compressed air to ISO 8573-1:2010 [-:3:-]. |
| Fluid Medium | Compressed Air |
| Body Material | Zinc |
| Bowl Material | Zinc Bowl with Clear Nylon Sight Glass |
| Bowl Ring | Aluminum |
| Seal Material | Nitrile (Buna-N) |
| Weight | 2.9 lb (1.32 kg) |
+
